5,500 lb rated forks, manual width adjustment, and a walk-through carriage built for construction, agricultural, and material handling work.
Moving pallets of building materials, lumber, equipment, and farm supplies shouldn't require a separate forklift. The Prime Attachments Pallet Forks turn your skid steer into a practical material handling machine, helping you load trucks, unload deliveries, and move heavy materials around the jobsite with the equipment you already own.
The 5,500 lb rated forks feature a manually adjustable spacing system with a flip-lever locking mechanism. A professionally milled 1-1/4" x 3" upper slider bar has locking notches every 4 inches, allowing you to reposition the forks for different pallet widths. The reinforced 1/2" bottom slider bar provides additional support, while the walk-through carriage offers convenient access when entering or exiting the loader.
Choose from 4' or 5' carriage widths and 4' or 5' fork configurations to match your equipment and workload. These American-made pallet forks are built for contractors, farmers, landscapers, and property owners who need a dependable way to handle heavy materials without adding another machine to the fleet.
5,500 LB RATED FORKS
Heavy duty forks are rated for 5,500 lbs, providing a durable material handling attachment for pallets, lumber, equipment, and construction supplies.
MANUALLY ADJUSTABLE FORK SPACING
Reposition the forks along the carriage to accommodate different pallet widths and load sizes. A flip-lever locking system secures the selected position.
1-1/4" X 3" MILLED SLIDER BAR
The professionally milled upper slider bar features locking notches every 4 inches for repeatable manual fork positioning.
REINFORCED 1/2" BOTTOM SLIDER BAR
A professionally milled T-design lower slider bar provides additional structural support for the fork carriage during material handling operations.
WALK-THROUGH CARRIAGE
The open center carriage design provides a convenient access area for operators entering or exiting compatible skid steers when the attachment is safely lowered.
FOUR CARRIAGE AND FORK COMBINATIONS
Choose 4' or 5' carriage widths with either 4' or 5' fork options, including mixed configurations for different material handling requirements.
| Specification | Details |
|---|---|
| Manufacturer | Prime Attachments |
| Attachment Type | Manually Adjustable Skid Steer Pallet Forks |
| Mounting System | Skid Steer Quick Attach (SSQA) |
| Fork Rating | 5,500 lbs |
| Fork Adjustment | Manual Flip-Lever Locking System |
| Upper Slider Bar | 1-1/4" x 3" Professionally Milled Steel |
| Slider Bar Notches | Every 4" |
| Bottom Slider Bar | 1/2" Reinforced Milled T-Design |
| Carriage Design | Walk-Through |
| Carriage Options | 4' and 5' |
| Fork Options | 4' and 5' |
| Mixed Configurations | Available |
| Carriage Height | 37" |
| Hydraulics Required | No |
| Country of Manufacture | USA |
| Manufacturer Warranty | 2 Years |
| Model | Carriage | Forks | Weight |
|---|---|---|---|
| PF 4x4 | 4' | 4' | 463 lbs |
| PF 4x5 | 4' | 5' | 493 lbs |
| PF 5x4 | 5' | 4' | 495 lbs |
| PF 5x5 | 5' | 5' | 600 lbs |
| Dimension | 4' Option | 5' Option |
|---|---|---|
| Carriage Width | 47.25" | 59.25" |
| Fork Length | 56" | 68" |
| Carriage Height | 37" | 37" |
Choosing a Configuration: The first measurement identifies carriage size, and the second identifies fork size. For example, PF 4x5 combines a 4' carriage with the 5' fork option.
Manual vs. Hydraulic Adjustment: These pallet forks use a manual flip-lever system to reposition and lock the forks. Hydraulic fork spacing adjustment is available on Prime Attachments' separate Hydraulic Sliding Pallet Fork model.
Lifting Capacity: The forks are manufacturer rated for 5,500 lbs. Actual allowable lifting capacity depends on your skid steer's rated operating capacity, attachment weight, load center, and operating conditions. The fork rating does not mean every skid steer can safely lift 5,500 lbs.
Machine Compatibility: Designed for compatible skid steers equipped with the Skid Steer Quick Attach mounting system. No auxiliary hydraulic connection is required for fork adjustment.
