Combine the carrying ability of a solid bucket with two independent hydraulic grapples, a 34" opening, and reinforced Grade 50 steel construction.
Moving loose dirt is one job. Picking up tangled brush, broken concrete, and awkward debris is another. Switching attachments every time the material changes slows everything down. The Prime Attachments Heavy Duty Grapple Bucket combines a solid material bucket with two independently operating hydraulic grapples, allowing you to scoop loose material, secure uneven loads, and keep working without constantly changing equipment.
The 34" grapple opening provides room to handle brush, logs, rocks, and demolition debris, while independent grapple arms adjust to irregular loads. Unlike an open tine grapple, the solid bucket floor retains dirt, gravel, and smaller material instead of letting it fall through during transport.
Built from 1/4" Grade 50 steel bucket material, the attachment features reinforced grapple arms, removable side plates, and six heavy underside supports. A 1/2" bolt-on reversible cutting edge provides a serviceable working edge for loading and grading. Available in 68", 72", 78", and 84" widths, this American-made attachment is designed for contractors, farmers, and property owners handling demanding cleanup and material moving jobs.
DUAL INDEPENDENT HYDRAULIC GRAPPLES
Two independently operating grapple arms help secure uneven loads, from tangled branches and logs to broken concrete and demolition debris.
34" GRAPPLE OPENING
The wide grapple opening provides room for bulky material while allowing the hydraulic arms to clamp down on irregular loads during handling.
SOLID GRADE 50 STEEL BUCKET
The 1/4" steel bucket floor retains dirt, gravel, and loose debris that would otherwise fall through an open tine grapple.
1/2" BOLT-ON REVERSIBLE CUTTING EDGE
The replaceable cutting edge can be reversed as it wears, helping extend service life and simplifying future maintenance.
REMOVABLE SIDE PLATES
Heavy 1/2" bolt-on side plates help contain loose material and can be removed when the job calls for a more open bucket configuration.
REINFORCED FRAME AND VISIBILITY CUTOUTS
Six underside supports strengthen the bucket, while cutouts in the grapple arms help operators see the load and working area when the grapples are raised.
| Specification | Details |
|---|---|
| Manufacturer | Prime Attachments |
| Attachment Type | Heavy Duty Skid Steer Dirt Bucket Grapple |
| Mounting System | Skid Steer Quick Attach (SSQA) |
| Available Widths | 68", 72", 78", and 84" |
| Grapple Opening | 34" (2026 Product Catalog) |
| Grapple Configuration | Two Independent Hydraulic Grapples |
| Hydraulic Cylinders | Two 3,000 PSI Cylinders |
| Bucket Material | 1/4" Grade 50 Steel |
| Grapple Sides | 1/2" Steel |
| Grapple Flats | 5/16" Steel |
| Cutting Edge | 1/2" Bolt-On Reversible Steel |
| Side Plates | 1/2" Bolt-On Removable Steel |
| Underbody Supports | Six 1/2" x 3" Steel Supports |
| Pivot Points | Greaseable |
| Grapple Visibility | Cutouts in Grapple Arms |
| Overall Length | 38" |
| Overall Height | 28" |
| Primary Applications | Dirt, Gravel, Brush, Logs, Rocks, and Demolition Debris |
| Country of Manufacture | USA |
| Manufacturer Warranty | 2 Years |
| Model | Width | Weight |
|---|---|---|
| DBG 68 | 68" | 900 lbs |
| DBG 72 | 72" | 950 lbs |
| DBG 78 | 78" | 1,000 lbs |
| DBG 84 | 84" | 1,050 lbs |
Independent Grapple Operation: Each upper grapple operates independently to help secure loads with uneven shapes and heights. This makes the attachment useful for carrying irregular material that may not clamp evenly with a single full-width grapple.
Bucket vs. Open Tine Grapple: The solid bucket floor is designed to retain dirt, gravel, and smaller debris. Prime's open tine grapples are better suited to separating larger material from loose soil.
Machine Compatibility: Designed for compatible skid steers equipped with the Skid Steer Quick Attach mounting system and auxiliary hydraulics. Confirm your machine's operating capacity, hydraulic connections, and attachment weight before selecting a size.
