Move round hay bales with a 49" German forged center spear, two 17" stabilizer spears, and a 2,700 lb rated capacity.
Moving round bales shouldn't mean fighting a load that wants to roll or swing every time you lift it. The Prime Attachments 3 Prong Bale Spear uses a 49" center spear and two lower stabilizer spears to help keep hay bales securely positioned while transporting, loading, or stacking them around the farm.
The main spear is made from German forged steel and measures 1-3/4" in diameter. Two 17" zinc plated stabilizer spears support the bale from below, helping reduce unwanted movement during handling. All three spears are replaceable, making it easier to maintain the attachment as components wear.
Built with a rigid 3" x 3" steel tubing frame, this bale spear has a manufacturer rated capacity of 2,700 lbs while weighing just 175 lbs itself. Its Skid Steer Quick Attach (SSQA) mounting system connects to compatible loaders, giving farmers and ranchers a straightforward way to handle round bales using equipment they already own.
49" GERMAN FORGED CENTER SPEAR
The long center spear penetrates the bale to provide the primary lifting support, making it useful for transporting and positioning large round hay bales.
DUAL 17" STABILIZER SPEARS
Two lower spears help prevent round bales from rolling or swinging while being lifted and transported.
2,700 LB RATED CAPACITY
The three spear arrangement has a manufacturer rated capacity of 2,700 lbs for hay handling applications, subject to the loader's actual lifting capacity.
REPLACEABLE SPEAR DESIGN
All three spears can be replaced individually. The lower stabilizer spears use nut and bolt connections for serviceability.
3" X 3" STEEL TUBING FRAME
The rigid steel frame provides a durable mounting structure for repeated bale loading, transporting, and stacking around the farm.
SKID STEER QUICK ATTACH MOUNTING
Connects to compatible SSQA equipped skid steers, allowing operators to handle hay bales without a dedicated bale handling machine.
| Specification | Details |
|---|---|
| Manufacturer | Prime Attachments |
| Model / SKU | BS 3 |
| Attachment Type | 3 Prong Skid Steer Bale Spear |
| Mounting System | Skid Steer Quick Attach (SSQA) |
| Rated Capacity | 2,700 lbs |
| Number of Spears | 3 |
| Center Spear Length | 49" |
| Center Spear Diameter | 1-3/4" |
| Center Spear Material | German Forged Steel |
| Stabilizer Spear Quantity | 2 |
| Stabilizer Spear Length | 17" |
| Stabilizer Spear Diameter | 1-1/4" |
| Stabilizer Spear Finish | Zinc Plated |
| Stabilizer Spear Mounting | Nut and Bolt Connections |
| Spear Replacement | All Three Spears Replaceable |
| Frame Construction | 3" x 3" Steel Tubing |
| Overall Length | 52" |
| Overall Width | 49" |
| Overall Height | 23.5" |
| Attachment Weight | 175 lbs |
| Primary Application | Round Hay Bale Lifting, Transporting, and Stacking |
| Country of Manufacture | USA |
| Manufacturer Warranty | 2 Years |
Three Prong vs. Two Prong Bale Spear: This model uses one long center spear and two shorter lower stabilizer spears to help control round bale movement. Prime also offers a separate two prong model with two full length spears for handling round and square bales.
Load Capacity: The attachment carries a manufacturer rating of 2,700 lbs. Actual allowable bale weight depends on your skid steer's rated operating capacity, the attachment's 175 lb weight, load position, and operating conditions.
Machine Compatibility: Designed for compatible skid steers equipped with the Skid Steer Quick Attach mounting system. Confirm your loader's mounting system and available lifting capacity before ordering. No auxiliary hydraulics are required.
